Boss BR-1180CD Digital Recording Studio Pictures

Acquired: 7/20/2004 - eBay Auction

(Click on each picture to see a larger version)
BR-1180CD Picture 1 BR-1180CD Picture 2
BR-1180CD Picture 3 BR-1180CD Picture 4
BR-1180CD Picture 5 BR-1180CD Picture 6
BR-1180CD Picture 7 BR-1180CD Picture 8

Specifications
Manufactured:1998
Tracks: Tracks: 10
V(irtual)-Tracks: 80 (8 V-Tracks per each Track)
Hard Drive:20 GB
Front Panel: POWER switch
SENS(itivity) knob
Peak indicator
INPUT SELECT buttons
   GUITAR/BASS, MIC 2:
   MIC 1:
   LINE:
   SIMUL(taneous):
EFFECTS buttons
INPUT LEVEL knob
TUNER ON/OFF button
REC(ording) MODE button
   INPUT:
   BOUNCE:
   MASTERING:
REC(ording) MODE indicators
MARKER buttons
   MARK:
   SEARCH |<<:
   SEARCH >>|:
   CLEAR:
AUTO PUNCH IN/OUT buttons
   ON/OFF:
   IN:
   OUT:
   DELETE:
ZERO button
REW(ind) button
F(ast) F(orward) button
REPEAT button
STOP button
PLAY button
REC(ording) button
PAN button
EQ(ualizer) button
CHORUS/DELAY button
REVERB button
AUDIO TRACK MIXER faders 1-8, 9/10
REC(ording) TRACK buttons 1-8, 9/10
PHRASE TRAINER buttons
   CENTER CANCEL:
   TIME STRETCH:
MASTERING TOOL KIT button
STEREO RHYTHM/LOOP
   AUTO/ON/OFF button:
   EDIT button:
   Fader 11:
   TAP button:
V-TRACK button
TRACK MUTE button
UTILITY button
UNDO/REDO button
TIME/VALUE dial
CURSOR buttons
ENTER/YES button
EXIT/NO button
MASTER fader
CD-R/RW
   AUDIO CD WRITE/PLAY button:
   DATA SAVE/LOAD button:
   LOOP PHRASE IMPORT button:
MIDI indicator
HD ACCESS indicator
DISPLAY
   MARKER:
   MEASURE:
   TI,E:
   FRAME:
   INFORMATION:
   MIXER/TRACK:
   MASTER:
Rear Panel: GUITAR/BASS jack
MIC 2 jack (TRS Phone)
MIC 2 connector (XLR Type)
MIC 1 (VOCAL) jack (TRS Phone)
MIC 2 (VOCAL) connector (XLR Type)
LINE IN jacks
LINE OUT jacks
PHONES VOLUME knob
PHONES jack
EXP(ression) PEDAL jack
FOOT switch jack
DIGITAL OUT connector
MIDI IN connector
MIDI OUT connector
AC Adapter jack
