Boss FZ-5 Fuzz Pictures

Acquired: 3/6/2008 - Music 123

(Click on the picture to see a larger version)
FZ-5 Fuzz Picture

Controls: LEVEL knob
MODE knob
    F - Face (Models the Dallas-Arbiter FUZZ FACE)
    M - Mst Fuzz (Models the Maestro FZ-1A)
    O - Octave Fuzz (Models the Octavia fuzz)
FUZZ knob
Pedal switch
Indicator: CHECK indicator
(Used for indication of check battery)
Connectors: Input Jack
Output Jack
AC Adaptor Jack (DC 9 V)
