Vox North Coast Music Super 'B' Pictures

(AD120VTH Head & AD412 Cabinet,
re-badged & re-grilled by North Coast Music
to look like a Super Beatle)

Acquired: 4/23/2004 - North Coast Music

(Click on each picture to see a larger version)

Specifications - Head Manufactured: 2004 Model: AD120VTH Serial Number: 000976 Type: Tube, Solid State Tubes: (2) 12AX7 Ohms: 8 Channels: 2 Power Output: 120 Watts Top Panel: INPUT   HIGH input jack   LOW input jack PEDAL  Selector switch   COMP: Compressor   OCTAVE: Octave Divider   ACOUSTIC: Acoustic Simulation   TREBLE BOOST: Treble Booster   VOX WAH: Classic V847   TUBE OD: Tube Overdrive   AUTO WAH: Auto Wah-Wah   FAT OD: Heavy Overdrive   U-VIBE: Uni-Vibe   FUZZ: Fuzz effect  Pedal Selected LED indicator  DRIVE knob  LEVEL knob   Drive & Level Effects   PEDAL   DRIVE   LEVEL   COMP   Sensitivity   Level   OCTAVE   Direct Level   Octave Level   ACOUSTIC   Treble   Bass   TREBLE BOOST   Drive   Level   VOX WAH   Pedal   N/A   TUBE OD   Drive   Level   AUTO WAH   Attack   Sensitivity   FAT OD   Drive   Level   U-VIBE   Speed   Mix   Sensitivity   Drive   FUZZ PREAMP/POWER AMP  AMP TYPE Selector switch   VOX AC15   VOX AC15TB   VOX AC15TB   VOX AC30   VOX AC30TB   UK BLUES   UK ’70S   UK ’80S   UK ’90S   UK MODERN   RECTO   US HIGAIN   BOUTIQUE OD   BOUTIQUE CL   BLACK 2x12   TWEED 1x12   TWEED 4x10  GAIN knob  VOLUME knob  TREBLE knob  MIDDLE knob  BASS knob  PRESENCE knob  MASTER knob MODULATION  TYPE button   CHORUS LED indicator   FLANGER LED indicator   PHASER LED indicator   TREMOLO LED indicator   ROTARY LED indicator  EX CTL(External Control) button  EX CTL LED indicator  SPEED knob  DEPTH knob   Speed & Depth Effects   MODULATION TYPE   SPEED   DEPTH   CHORUS   Speed   Depth   FLANGER   Speed   Octave Level   PHASER   Speed   Feedback   TREMELO   Speed   Feedback   ROTARY   Speed   Depth DELAY  TYPE button   DELAY LED indicator   TAPE ECHO LED indicator   MULTI HEAD LED indicator  TAP button  TAP LED indicator  FEEDBACK knob  DEPTH knob REVERB  TYPE button   SPRING LED indicator   ROOM LED indicator   PLATE LED indicator  DEPTH knob BYPASS  ORIGINAL VALUE LED indicator  ORIGINAL VALUE button BANK/MANUAL/WRITE/TUNER/CHANNEL  BANK LED indicator  UP button  DOWN button  WRITE button  TUNER/CANCEL button  CHANNEL Select buttons (1 - 4) POWER  POWER LED indicator  POWER switch Rear Panel: Power input jack OUTPUT IMPEDANCE SELECT switch   16 ohm   8 ohm   4 ohm SPEAKER OUT  R CH 1 ouput jackl  R CH 2 ouput jackl  L CH 1 ouput jackl  L CH 2 ouput jackl LOOP  SEND R ouput jackl  SEND L ouput jackl  RETURN R ouput jackl  RETURN L ouput jackl POWER SELECT switch   1x2 (1 Watt + 1 Watt)   15x2 (15 Watt + 15 Watt)   30x2 (30 Watt + 30 Watt)   60x2 (60 Watt + 60 Watt) FOOT CONTROLLER input jack LEVEL   LEVEL knob PHONE OUT output jack LINE OUT R output jack LINE OUT L output jack

Specifications - Cabinet Manufactured: 2004 Model: AD412 Max Input: 160W (UR) stereo 320W mono Input Impedance: 8 Ohm (UR) stereo 16 Ohm mono 4 Ohm mono Speakers: (4) 12" Vox NeoDog Original Neodymium Speaker (Celestion) 16 Ohm x 4 Enclosure: Closed back cabinet
